Denon DP-300F Service Manual

7
DP-300F
PARTS LIST OF P.W.B. UNIT ASS’Y
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
EQ P.W.B. ASS'Y
RECTIFYER P.W.B. ASS'Y
MICRO SWITCH AND WIRE ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SW101 00D 941 0014 001 Slide Sw(SBB-22-14) 1
- Elec. Capacitor(4.7uF/50V,M,Bulk 5*11) 1
IC101 00D 263 0434 002 IC(LA3161) 1
C108,208 - Ceramic Capacitor(4700pF/50V K Y5P Taping) 2
C102,107 - Elec. Capacitor(4.7uF/50V,M,Taping 5*11) 2
C202,207 - Elec. Capacitor(4.7uF/50V,M,Taping 5*11) 2
C104,204 - Elec. Capacitor(47uF/25V,M,Taping 5*11) 2
C105,205 - Polyester Capacitor(0.027uF/50V Taping) 2
C101,201 - Ceramic Capacitor(100pF/50V K SL Taping) 2
C103,203 - Ceramic Capacitor(330pF/50V K SL Taping) 2
C106,206 - Polyester Capacitor(0.0082uF/50V Taping) 2
C301,302 - Elec. Capacitor(100uF/16V,M,Taping 6.3*11) 2
R107,207 - Carbon Film Resistor(100K Ohm J 1/6W Taping 26mm) 2
R105,205 - Carbon Film Resistor(9.1K Ohm J 1/6W Taping 26mm) 2
R101,201 - Carbon Film Resistor(470 Ohm J 1/6W Taping 26mm) 2
R103,203 - Carbon Film Resistor(200 Ohm J 1/6W Taping 26mm) 2
R102,202 - Carbon Film Resistor(47K Ohm J 1/6W Taping 26mm) 2
R106,206 - Carbon Film Resistor(680 Ohm J 1/6W Taping 26mm) 2
R108,208 - Carbon Film Resistor(1K Ohm J 1/6W Taping 26mm) 2
R104,204 - Carbon Film Resistor(150K Ohm J 1/6W Taping 26mm) 2
R301 - Carbon Film Resistor(120 Ohm J 1/4W Taping 26mm) 1
L101,102 00D 958 0016 900 Bead Core (86-019-A TAPING) 2
J01 - Jumper 1
Ref. No. Part No. Part Name Remarks Q'ty New
C1 00D 254 4539 705 Elec. Capacitor(1000uF/16V,M,Bulk 13*21) 1
C3 00D 254 4538 971 Elec. Capacitor(470uF/16V,M,Bulk 10*12) 1
D1-D4 00D 941 0013 002 Diode(1N4002,1A/100V,Bulk) 4
Ref. No. Part No. Part Name Remarks Q'ty New
SW101 00D 212 0442 009 Speed Switch (SW101) 403-DP300F-255 1
2
2
2
2
2
2
2
2
2
2
2
2
2
2

Denon DP-300F Specifications

General

Type	Belt-drive audio turntable
Interface	PHONO
Product color	Black, Silver
Wow & flutter	0.1 %
Nominal speeds	33 1/3, 45 RPM
Stylus pressure	4 g
Signal-to-Noise Ratio (SNR)	60 dB
Arm length	221.5 mm
AC adapter frequency	60 Hz
AC adapter input voltage	80 - 260 V
Power consumption (typical)	2 W
Frequency range	20 - 20000 Hz

Weight and Dimensions

Weight	5500 g
Product dimensions (WxHxD)	434 x 381 x 122 mm
