Denon DP-300F Service Manual

17
DP-300F
12
3
45
6
7
8
A
B
C
D
E
RCH
LCH
EQ PWB ASSY
C301
100/16
0.022
R301
120
C302
100/16
R208
1K
R206
680
R205
9.1K
R204
150K
C208
4700P
C205
0.027u
C206
0.0082u
C207
4.7/ 50
R207
100K
OUTPUT
C203
330P
C202
4.7/ 50
C201
100P
R203
200
C204
47/16
R202
47K
R201
470
R108
1K
R106
680
R105
9.1K
R104
150K
C108
4700P
C105
0.027u
C106
0.0082u
C107
4.7/ 50
R107
100K
R103
200
C104
47/16
C103
330P
C102
4.7/ 50
C101
100P
R102
47K
R101
470
BLK
WHITE
RED
CARTRIDGE
12
SW 3
12
SW 2
1
2
SW 1
SPEED SELECT SW
M
-
+
DC MO TOR
45
33
C1
1000/16
D2
D4
D1
D3
PO
POWER PWB ASSY
WER
TRANSFORMER
D1-D4 1N 4002*4
2
1
3
SW101
SW101
2
1
3
+
1
-
2
3
45
IC 101A
1/2 LA3161
+
8
-
7
6
45
IC101B
1/2 LA3161
R+
R-
L+
L-
BLUE
GR EEN
TRANS
AC IN
405-PXE90-091C
405-PXE90-090A
L101
FB
L102
FB
C3
470u/16V
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS

Denon DP-300F Specifications

General

Type	Belt-drive audio turntable
Interface	PHONO
Product color	Black, Silver
Wow & flutter	0.1 %
Nominal speeds	33 1/3, 45 RPM
Stylus pressure	4 g
Signal-to-Noise Ratio (SNR)	60 dB
Arm length	221.5 mm
AC adapter frequency	60 Hz
AC adapter input voltage	80 - 260 V
Power consumption (typical)	2 W
Frequency range	20 - 20000 Hz

Weight and Dimensions

Weight	5500 g
Product dimensions (WxHxD)	434 x 381 x 122 mm
