Denon RCD-M37DAB Service Manual

56
RCD-M37 / RCD-M37DAB / D-E500 / D-M37
PARTS LIST OF P.W.B. UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.\
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada mode E2 : Europe model EK : U.K. model JP : Japan model
MCU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC20 90M-HC109100R IC, RESET RICOH 1.8V
HVIRH5VT18C
IC21 943243001110S IC, USB TMP92FD28AFG CVITMP92FD28AFG *
IC22,23 00D9430183608 IC, ITC74HCU04AFNG
HVI74HCU04AFNG
IC24 943243004700D IC, FLASH U-COM T5CC1 CVIANAM1428CR
(081024-01)
*
IC27 90M-HC110060R IC, CD DSP
CVITC94A70FG
IC31 00D9430209701 IC, REGULATOR(KIA1117S/F33) CVIKIA1117S33
IC32 90M-HC900160R IC, REGULATOR(LM1117S15) CVIKIA1117S15
IC33 90M-HC108390R IC, AT24C08N10SC2.7 HVIAT24C08N10SC
IC34 00D9430184209 IC, MOTOR DRIVER (Pb Free) HVITA2125AFG
IC35 943239001120S IC, CURRENT LIMITER CVIRT9702APB *
IC36 00D9430158400 IC, 74VHC04M
HVI74VHC04MX
D201,202 00D9430041106 DIODE, RB160L-60TE25
HVDRB160L60TE25
D204 00D9430041106 DIODE, RB160L-60TE25 HVDRB160L60TE25
D205,206 943209001080S DIODE, CHIP CVD1SS355T *
D301,303 943209001080S DIODE, CHIP
CVD1SS355T *
Q201,202 00D9430038009 TR, KRA102S
HVTKRA102S
Q205 00D9430037903 TR, KRC102S HVTKRC102S
Q210 00D9430038009 TR, KRA102S HVTKRA102S
Q214 00D9430038009 TR, KRA102S HVTKRA102S
Q301 00D9430058908 TR, KTA1504S Y RTK HVTKTA1504SYRT
K
CAPACITORS GROUP
C203,204 nsp CAP, CHIP(12PF/50V/COG/1608)
CCUS1H120JA
C205 nsp CAP, CHIP 10PF 50V CCUS1H100JA
C206 nsp CAP, CHIP(12PF/50V/COG/1608) CCUS1H120JA
C208-210 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C211 nsp CAP, CHIP ELECT 100UF/6.3V HCEC0JRV2101T
C212 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C214-216 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C218 nsp CAP, CHIP ELECT 100UF/6.3V HCEC0JRV2101T
C219 nsp CAP, CHIP 100PF 50V CCUS1H101JA
C221-224 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C225 943134001130S CAP, SMD ELECT
(MANLEX RV, 16V/470, 10X10)
CCEC1CRV471T *
C226 nsp CAP, CHIP ELECT 10UF / 16V
HCEC1CRV2100T
C227 nsp CAP, CHIP 0.01UF 50V CCUS1H103KC
C228 nsp CAP, CHIP 220PF 50V CCUS1H221JA
C229 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C230 nsp CAP, CHIP ELECT HCEC0JRV102T
C231-235 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C236 nsp CAP, CHIP 0.01UF 50V CCUS1H103KC
C238-245 nsp CAP, CHIP 0.1UF 50V CCUS1H104KC
C246,247 nsp CAP, CHIP 0.01UF 50V CCUS1H103KC
