DeWalt DCN691 User Manual

English
21
In addition to the
warranty, DeWALT
tools are covered by
our:
1 YEAR FREE sERViCE
DeWALT will maintain
the tool and replace
worn parts caused by
normal use, for free, any
time during the first year
after purchase.
2 YEARs FREE sERViCE
On DEWAlT BATTERY
PACKs
DC9071, DC9091,
DC9096, DC9182,
DC9280, DC9360,
DCB120, DCB127,
DCB201, DCB203, DCB203BT, DCB207, DCB361 3 YEARs FREE sERViCE On DEWAlT
BATTERY PACKs
DCB200, DCB204, DCB204BT, DCB205, DCB205BT, DCB206,
DCB606, DCB609
nOTE: Battery warranty voided if the battery pack is tampered with in any way.
DeWALT is not responsible for any injury caused by tampering and may
prosecute warranty fraud to the fullest extent permitted by law.
90 DAY MOnEY BACK gUARAnTEE
If you are not completely satisfied with the performance of your DeWALT Power
Tool, Laser, or Nailer for any reason, you can return it within 90 days from the
date of purchase with a receipt for a full refund – no questions asked.
lATin AMERiCA: This warranty does not apply to products sold in Latin America.
For products sold in Latin America, see country specific warranty information
contained in the packaging, call the local company or see website for warranty
information.
FREE WARning lABEl REPlACEMEnT: If your warning
labels become illegible or are missing, call 1-800-4-DeWALT (1-800-433-9258) for a
free replacement.
TROUBLESHOOTING GUIDE
Many common problems can be solved easily by utilizing the chart below. For more serious or persistent
problems, contact a DeWALT service center or call 1-800-4-DeWALT.
WARNING: To reduce the risk of serious personal injury, ALWAYS disconnect battery pack from tool
before all repairs.
sYMPTOM
CAUsE
FiX
Motor does not run with
trigger depressed
Trigger lock in locked position.
Unlock trigger lock.
Tool is stalled, locking the motor
from rotating.
Rotate the stall release lever on the tool
and the mechanism will release. If driver
blade does not return, remove battery and
manually push driver blade back to home
position.
Tool is in the sequential actuation
mode.
Depress contact trip first before firing
or switch to bump mode.
Tool internal electronics need to
be reset.
Remove battery, wait 3 seconds and
reinsert.
Motor stops running after 5
seconds.
Normal operation, release trigger and
redepress.
Terminals are dirty or damaged.
See authorized service center.
Damaged internal electronics.
See authorized service center.
Damaged Trigger.
See authorized service center.
Motor does not run with
contact trip depressed
Trigger lock in locked position.
Unlock trigger lock.
Dryfire lock out engaged, blocking
contact trip from traveling fully.
Load more nails into magazine.
Tool is stalled, locking the motor
from rotating.
Rotate the stall release lever on the tool
and the mechanism will release. If driver
blade does not return, remove battery and
manually push driver blade back to home
position.
Bent contact trip.
See authorized service center.
