Specifications Value Air Distribution Box (ADB), Mechanical
4 Specifications
This section provides the electrical specifications by model.
Model
Nominal
Capacity
Cooling
(BTU HR)
Electrical
Rating
Compressor Amps Fan Motor Amps Refrigerant
R-410A
(oz)
Minimum
Wire Size
1
AC Circuit
Protection
2
(Installer
Supplied)
Minimum
Generator
Size
3
(1 Unit/
2 Units)
Rated
Load
Locked
Rotor
Rated
Load
Locked
Rotor
457915.70X
13,500 115 VAC,
60 HZ,
1 ph
12.4 63.0 2.5 5.8 18.0 12 AWG 20 Amp 3.5 kW/
5.0 kW
457915.71X
13,500 12.4 68.0 2.5 5.8 18.0
B57915.71X
13,500 12.4 68.0 2.5 5.8 18.0
459516.70X
15,000 13.3 66.0 2.0 5.6 27.5
459516.71X
15,000 13.3 70.0 2.0 5.6 27.5
B59516.71X
15,000 13.3 70.0 2.0 5.6 18.3
540315.70X
13,500 12.4 63.0 3.0 8.5 18.5
540315.71X
13,500 12.4 68.0 3.0 8.5 18.5
H540315.72X
13,500 12.7 68.0 2.8 8.0 19.5
540316.70X
15,000 13.3 66.0 2.8 7.6 29.5
540316.71X
15,000 13.3 70.0 2.8 7.6 29.5
H540316.72X
15,000 13.2 70.0 2.8 8.0 20.1
640312.80X
11,000 11.5 53.0 2.6 8.5 20.0
640312.83X
11,000 12.5 63.0 2.6 8.5 18.0
640312C.35X
11,000 10.5 53.0 3.5 10.0 19.0
640312C.85X
11,000 11.5 53.0 2.6 8.5 20.0
640315.80X
13,500 12.6 63.0 2.6 8.5 18.0
640315.83X
13,500 12.5 63.0 2.6 8.5 19.0
640315.84X
13,500 12.5 63.0 3.5 8.5 19.0
640315C.75X
13,500 12.7 52.0 2.6 8.5 14.5
640316C.75X
15,000 12.9 52.0 2.6 8.5 21.5
FJX3473MWHAS
13,500 13.6 61.0 3.3 6.9 12.7
FJX3473MBKAS
13,500 13.6 61.0 3.3 6.9 12.7
FJX3573MWHAS
15,000 13.6 73.0 3.3 6.9 13.4
FJX3573MBKAS
15,000 13.6 73.0 3.3 6.9 13.4
1
The wiring size indicated is for copper wiring up to 24  (7.3 m) in length. For wire lengths over 24  (7.3 m), consult the National Electrical Code for proper sizing.
2
Circuit protection: a time delay fuse or circuit breaker is required.
3
Dometic Corporation gives general guidelines for generator requirements. These guidelines come from experiences people have had in actual applications.
When sizing the generator, the total power usage of your RV must be considered. Generators may lose power at high altitudes and from lack of maintenance.
