CT4110, CTS4110 Cleaning and maintenance
27
7.2 Releasing the slider from the cassette
!
➤ Remove the cassette tank and place it on a firm surface (fig. d, page 9).
➤ Unlatch the slider handle and pull it out. (fig. e, page 9).
➤ Turn the slider anti-clockwise and release it from the cassette (fig. f, page 10).
In the state upon delivery and after extended use, the bayonet fitting can be
loosened only with difficulty.
7.3 Greasing the cassette seal
➤ Release the slider from the cassette (chapter “Releasing the slider from the
cassette” on page 27).
➤ Push back the cover so that the seal is accessible (fig. g, page 10).
➤ Clean and grease the seal.
!
➤ Close the cover (fig. k, page 11).
➤ Place the slider back on.
7.4 Cleaning the bayonet fitting and greasing the
bayonet seal
➤ Release the slider from the cassette (chapter “Releasing the slider from the
cassette” on page 27).
➤ Clean the bayonet fitting (fig. l 1, page 12) on the slider.
➤ Uniformly grease the bayonet seal (fig. l 2, page 12) with silicone grease.
➤ Place the slider back on.
CAUTION!
When the slider is closed during cleaning or greasing, there is a risk of
crushing body parts.
CAUTION! Danger of crushing!
Do not reach into the opening when you close the cover.
CT4000--O--USA.book Seite 27 Dienstag, 6. März 2018 1:39 13
