Dometic DM2663 Installation Manual

29
EN
Refrigerator
RM1350, RM1350SL
48
Screw
Top Panel
➤ Secure the refrigerator using two screws (not
provided) through the holes underneath the top
decoration panel.
➤ Seal the openings for the screws on the metal
frame using tape or sealant.
➤ Install the lower front strip by sliding it under the
bottom hinge plate. Refer to "6.3 Installing the
hinge plate" on page 29.
➤ Secure the refrigerator and the lower front strip
using two screws (not provided).
49
Screw
Ice Maker Cord
(optional)
➤ Install one screw (not provided) in the rear base.
An optional screw may be added on the opposite
side.
6.3 Installing the hinge plate
I
The refrigerator is provided with a lower front strip that is shipped as a loose part.
➤ Attach the front strip aer the refrigerator is set into the cutout opening.
50
Screw
Hinge
Plate
Front Strip
51
Screw
Hinge Plate
Front Strip
➤ Slide the lower front strip under the bottom hinge plate(s).
➤ Secure the hinge plate(s) and the lower front strip using two screws (not provided).
