Technical description Saneo B, Saneo C
22
4 Technical description
The cassette toilet Saneo consists of a toilet permanently installed in the vehicle and
a removable, mobile cassette as a holding tank. The cassette is externally accessible
through a door. Depending on the model, the toilet gets the rinse water from a tank
integrated in the housing or from a freshwater tank in the vehicle.
The following model versions of the toilet are available:
• Saneo B, Saneo C: freestanding, without water tank, without console
• Saneo BS, Saneo CS: freestanding, without water tank, with console
• Saneo BW, Saneo CW: freestanding, with a water tank in the console
• Saneo BLP, Saneo CLP: freestanding, without water tank, low console
Saneo C models can be equipped with an interval flush (optional). The water is
pumped into the toilet bowl in short spurts in order to achieve improved flush
wetting and cleaning. The wetting and cleaning depend on the amount of water
available in the vehicle.
4.1 Description of the components
No. in
fig. 1, page 3
Label
1 Housing for cassette tank
2 Draining slider for toilet bowl
3 Rotatable toilet bowl, plastic or ceramic
4 Lid and seat, removable
5Console
6 Control panel with level indicator and flushing
7
Only Saneo BW, CW
: Integrated freshwater tank
8
Only Saneo BW, CW: Tank flap (closable tank flap optional)
9 Cassette tank
10 Service door
