Installing the toilet Saneo B, Saneo C
24
5.3 Setting up the toilet
A
➤ Install the toilet according to the description for the respective model version.
➤ Set up the toilet so that it is flush to a vertical wall only.
➤ Leave at least 60 mm space to the side walls so that the swivelling of the upper
part of the toilet (with seat) is not restricted.
➤ For the installation, use the dimensional drawings and templates:
– Saneo B, Saneo C: fig. 4, page 5
– Saneo BS, Saneo CS: fig. 5, page 6
– Saneo BW, Saneo CW: fig. 5, page 6
– Saneo BLP, Saneo CLP: fig. 6, page 7
– Milling dimensions: fig. 7, page 8
– Drill holes: fig. 8, page 9
– Radii: fig. 9, page 10
I
5.4 Setting up the Saneo B, Saneo C toilet
The freestanding models Saneo B and Saneo C have no integrated water tank. Set
up this model so that the wall behind it can accommodate the control unit of the
toilet, the electrical connections and possibly a water tank. It is ideal if you put a box
in front of the room wall (fig. 0, page 11).
I
NOTICE!
All components of the system must be installed in frost-free areas.
In freezing temperatures, there is a risk of damage caused by frost.
NOTE
• For the templates for milling dimensions, drill holes and radii,
observe the symmetry point of the toilet (fig. 7 A, page 8,
fig. 8 A, page 9, fig. 9 A, page 10).
• When installing the toilet in a wet room, the manufacturer recom-
mends that you connect the toilet to the shower tray.
NOTE
Exemplary installation in a shower tray is shown in fig. 0, page 11 and
fig. a, page 11.
Saneo-B-Saneo-C--I-EN-DE-FR-IT-NL.book Seite 24 Montag, 20. Februar 2017 10:08 10
