Quick reference guide | Atlan SW 2.0n 15
Assembly and preparation
2 Assembly and preparation
The quick reference guide does not replace the instructions for use. Any use of the
medical device requires full understanding and strict observation of the instructions for use.
2.1 Selecting and connecting patient-specific accessories
2.1.1 Fitting the breathing circuit and the filters
The device can be used with Infinity ID breathing hoses or conventional breathing hoses. If
no leakage test has yet been performed after switching on the device, hose compliance and
hose resistance will automatically be adopted when Infinity ID breathing hoses are
connected.
1. Select suitable accessories for the respective patient category.
Complete device fail-
ure
If backup manual mode is activated:
– Manual ventilation or spontaneous breathing possible
– Emergency O
2 delivery (electronically controlled gas mixer)
or fresh-gas delivery (mechanically controlled gas mixer)
available
– Anesthetic agent delivery from connected vaporizers possi-
ble
Fault Safety function
Adults Pediatric
patients
Neonates
Tidal volume >700 mL 301 to 700 mL 50 to 300 mL <50 mL
Breathing bag 3L 2L 1L 0.5L
Breathing cir-
cuit
Adults Pediatric Neonates
(or pediatric)
Filter Filter or HMEF Use an HME or a
filter with low
resistance and
compliance.
Observe the fol-
lowing informa-
tion: "Permissible
hose configura-
tions", page 16.
