Technical data
Dräger Polytron 5200 / Dräger Polytron 53X0 25
8.7 Physical specifications
8.8 Environmental parameters
1)
not yet available
8.9 Ambient influences
See sensor data sheets.
Enclosure NEMA 4 x, IP 65/66/67
Size L x W x D approx.
without e-box
with e-box
7” x 5.8” x 5.1” (180 x 150 x 130 mm)
7.3” x 7.1” x 7.4” (185 x 180 x x190 mm)
Weight approx.
without e-box, aluminum
without e-box, stainless steel 316
with e-box, aluminum
with e-box, stainless steel 316
3.9 lbs (1.8 kg)
8.0 lbs. (3.6 kg)
6.9 lbs. (3.1 kg)
11.0 lbs. (5.0 kg)
Pressure
20.7 to 38.4 in. of hg
(700 to 1300 mbar)
Humidity 0% to 100% RH, non-condensing
Temperature
Sensor without relays with relays
DD / LC
-40 to 176 °F
(-40 to 80 °C)
-40 to 158 °F
(-40 to 70 °C)
DSIR / PIR 3000
1)
-40 to 149 °F
(-40 to 65 °C)
-40 to 149 °F
(-40 to 65 °C)
