PowerSeries Neo Installation Guide
Aux Loading and Battery Selection
HS2128/HS2064/
HS2032/HS2016
Board current draw mA
UL Residential Burg
ULC Residential Burg
UL Commercial Burg
UL Resi Fire
UL Home Health Care
ULC Resi Fire
ULC Com Burg
ULC Fire Monitoring
EN50131
Grade 2/Class II
Max AUX (NSC) current
loading
0.7A 0.7A 0.5A 0.5A 480mA
Max BELL (Alarm) current
loading
0.7A 0.7A 0.7A
0.7A (no local alarm
notification allowed, only
remote transmission to SRC)
0.7A
UL/ULC Listed enclosure
PC500C
PC5003C
CMC-1
PC4050CAR
PC5003C
PC5003C
PC4050CR (red/transfomer
mounted inside)
PC5003C
Power UC1
Transformer requirements
16.5V/40VA (plug in type)
PTC1640U (USA)
PTC1640CG (CAN)
FTC1637 (cUL listed)
16.5V/37VA (Hardwired
type, mounted inside the
enclosure or outside using
electrical box)
16.5V/40VA (hardwired
type, mounted inside the
cabinet)
Battery Capacity requirements 7Ah 7Ah
14Ah (2 x 7Ah in
parallel)
14Ah (2 x 7Ah in parallel) 7Ah
Standby Time
UL: 4 hours
ULC: 24 hours
4 hours 24 hours 24 hours 12 hours
Alarm time 4 minutes 15 minutes
4 min (UL resi fire)
5 min (Home Health
Care and ULC Resi Fire)
5 minutes (Alarm
Transmission only)
N/A
Recharging current setting mA, 700mA mA, 700mA mA, 700mA 480mA, 700mA 480mA, 700mA
EU Compliance Statement
This Product (HS218/HS2064/HS2032/HS2016) is in Conformity with EMC Directive 2004/108/EC based on results using harmonized
standards in accordance with article 10(5), R&TTE Directive 1999/5/EC based on Following Annex III of the directive and LVD directive 2006/95/EC based on results using
Harmonized standards.
This product meets the requirements of Class II, Grade 2 equipment as per EN50131-1: 2006+A1:2009, EN50131-3:2009, EN50131-6:2008 (Type A), EN50136-1-1:1997,
EN50136-2-1, EN50136-2-3 (ATS2) Standards.
This device is suitable for use in systems with the following notification options.
A (use of two warning devices and internal dialer required
B (self-powered warning device and internal dialer required
C (use of DSC compatible alternate communicator in back-up or redundant mode)
D (use of DSC compatible alternate communicator with encryption enabled required.)
For EN50131 compliant installations only the intrusion portion of the alarm system has been investigated. Fire Alarm and Auxiliary (Medical) Alarm functions were not included in
the evaluation of this product under the requirements of the above mentioned standards.
Additional features implemented for EN 50131 Grade 2:
Fire alarm and CO alarm annunciation
Auxiliary (medical) alarm annunciation
Optional feature implemented for EN 50131 Grade 2:
Removal from mounting tamper detection for non wire-free components
The model HS2128, HS2064, HS2032, HS2016 Control Panel has been certified by Telefication according to EN50131-1:2006 +A1:2009, EN50131-3:2009, EN50131-6:2008
(Type A) and EN50136-1:1997 (ATS2) for Grade 2, Class II.
Europe
This product is in conformity with: EMC Directive 2004/108/EC based on results using harmonized standards in accordance with article 10(5), R&TTE
Directive 1999/5/EC based on following Annex III of the directive and LVD Directive 2006/95/EC based on results using harmonized standards. The
product is labelled with the CE mark as proof of compliance with the above mentioned European Directives. Also a CE declaration of conformity (DoC)
for this product can be found at www.dsc.com under Agency Listings section.
- 21 -
