Section 4: DLS Programming
9
Section 4: DLS Programming
4.1 Local Programming with PC-Link
Follow the steps below in the sequence indicated to set up local programming using DLS:
New installations (refer to Section 1.1 Installation: on page 2)
1. Remove the Alarm System from the Wall Mount or Desk Mount.
2. Connect the AC Wiring.
In a new installation the backup battery requires 24 Hrs. charging. AC Power is required for PC-Link Programming until
battery is charged.
3. Connect the PC-Link cable between the computer (with DLS Software installed) and the header pins on the alarm system.
Connecting the DLS PC to the system will automatically initiate the connection.
4. When programming has been completed, remove the PC-Link cable
5. Complete the installation.
4.2 Remote Programming (via telephone line)
Refer to Section “[401] Downloading Options” on page 24 and page 39 for details.
AC Power must be present for the alarm system to answer incoming calls from DLS.
