Ducati Hyperstrada User Manual

Rear brake pedal.
Loosen counter nut (7).
Turn pedal stroke adjusting screw (6) until pedal is in
the desired position. Tighten the counter nut (7).
Operate the pedal by hand to check that there is 1.5
to 2 mm of freeplay before the brake bites. If not,
check to modify the length of the cylinder push-rod in
the following mode.
Slacken off the counter nut (10) on the pushrod.
Screw the pushrod (8) into the fork (9) to increase the
free play, or screw it out to reduce it.
Tighten the counter nut (10) and recheck the pedal
freeplay.
9
10
6 7
8
Fig. 86
137
