Ducati Hyperstrada User Manual

Check brake pads for wear
Check brake pads wear through the inspection hole
in the callipers.
Change both pads if friction material thickness of
even just one pad is about 1 mm.
Warning
Friction material wear beyond this limit would
lead to metal support contact with the brake disc thus
compromising braking efficiency, disc integrity and
rider safety.
Important
Have the brake pads replaced at a Ducati Dealer
or authorised Service Centre.
MIN
Fig. 131
MIN
Fig. 132
174

Ducati Hyperstrada Specifications

General

Transmission	6-speed
Frame	Tubular steel Trellis frame
Exhaust	2-1-2 system with catalytic converter and 2 lambda probes
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive linkage with adjustable Sachs monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Fuel Tank Capacity	16 liters (4.2 US gal)
Fuel Injection	Electronic fuel injection, 53 mm throttle bodies
