Duplo DB-250 User Manual

3
3. Part names
(1) Nipping Station
(2) Glue Tank
(3) Notching Station
(4) Clamp Station
(5) Control Panel
(6) Nipping Pressure Control
4. Names and functions of the control panel
No. Name Function LED Display /
Example
1 EMERGENCY Stop all the actions of the machine.
Except when “HOT” shows on the
LED display.
“STOP” (flashing)
2 STAND BY /
LED
Temporarily lowers the temperature
of glue tank so it won’t burn the glue
when the machine is not operated.
WARM__
3 CLOSE Close clamp.
4 LED DISPLAY 1) The amount of books bound. ____100
2) Operating status. BIND
3) Perform self-test and stir
the hot melt glue.
S-TEST
4) Error messages. ERR = L1
