58
11. TROUBLESHOOTING GUIDE
Problem Correct
Check
The paper is not aligned neatly.
The paper is not folded at the
center.
The paper is not stapled at the
center.
The staple has jammed.
The paper is not aligned neatly at
the paper receiving tray.
The DC-10 does not start.
Only the cover sheet is damaged
in saddle-stapling/folding and
center-folding only mode.
• Refer to “4-8. Raising the Binding
Accuracy”.
• Refer to “4-8. Raising the Binding
Accuracy”.
• To increase the feeding amount:
Use a metallic ball.
• To decrease the feeding amount:
Use a plastic ball.
• Refer to “4-8. Raising the Binding
Accuracy”.
• Adjust the clearance with the
clearance adjusting plate.
• To increase the feeding amount:
Use a metallic ball.
• To decrease the feeding amount:
Use a plastic ball.
• Finely adjust the width between
the stoppers.
• Reset.
• Select the appropriate position
while continuing operations.
• Perform inspections according to
the monitor lamp lit.
• Close.
• Set to the automatic mode.
• Memorize the setting with the
memory key.
• Refer to “4-2. Adjusting the Press
Roller Clearance”.
• Clean the press roller if it is dirty.
• When binding 64 g/m
2
paper, use
paper above 80 g/m
2
for the
cover.
• Check if the side jogger is set too
wide.
• Check if the back jogger is set
too wide.
• Check if the side jogger is set to
narrow.
• Check if the ball unit is
appropriate.
• Check if the side jogger is set too
narrow.
• Check if the ball unit is
appropriate.
• Check the folding position
stopper position.
• The staple cartridge is not
attached properly.
• Check if the paper guide roller
unit position set is appropriate.
• Check if the monitor lamp on the
control panel of the unit is lit.
• Check if the top cover of the unit
is open.
• Check if the unit is set to the
manual mode.
• Check if the unit is set to the fine
adjustment mode.
• Check if the clearance of the
press roller is appropriate for the
thickness of the paper.
• Check if less than 64 g/m
2
paper
is used.
To Next Page
