DUPLOMATIC E.M.DDC4-400V/RK RELEASE 1.9 07-09
EM DDC4-400-RK-0709gb.doc 14
OPERATING FUNCTION N°4: JOG
The disc will rotate of one step in the selected direction.
Proceed as follows
1. Clear all alarms (if present);
2. Set the operating function:
INPUTS OPERATING FUNCTION N°4:
MODE01 MODE02 MODE03
Next station in CW or CCW
0 0 1
3. Select direction:
PBIT01 PBIT02
Rotation in CW
1 0
Rotation in CCW
0 1
4. Set PSTART for give the confirmation of the movement in 5 s.
(It must stay ON for more than 30 ms).
OPERATING FUNCTION N°5: SERVICE
The turret cycle can be executed “step by step”: unlocking, rotation, locking.
Proceed as follows
1. Clear all alarms (if present);
2. Set an operating function:
INPUTS OPERATING FUNCTION N°5:
MODE01 MODE02 MODE03
Service
1 0 1
3. Select a command:
PBIT01 PBIT02 PBIT04 PBIT08 PARITY
Locking
0 0 1 0 0
Unlocking
0 0 0 1 0
Next tool CW
1 0 0 0 1
Next tool CCW
0 1 0 0 1
Continuos rotation
CW
1 0 0 0 0
Continuos rotation
CCW
0 1 0 0 0
4. Set PSTART for give the confirmation of the movement within 5 s.
(It must stay ON for more than 30 ms).
Locking and unlocking don’t require PSTART signal.
The unclamping function keeps the motor enabled, so it is necessary to go in emergency mode and switch
off the three phase supply to safely operate the disc by hand.
The clamping function is active only if the previous operation was the unclamping.
