DUPLOMATIC E.M.DDC4-400V/RK RELEASE 1.9 07-09
EM DDC4-400-RK-0709gb.doc 9
SELECTION OF THE NUMBER OF POSITIONS
The turret can be easily configured for two different number of positions simply setting two digital inputs of the
control units. No mechanical operations or part replacement are required. The value of the two settings can be
changed by PC.
Software
8/12 tools 6/12 12/24 8/16
Tools N°
8 12 6 12 12 24 8 16
PTAB01
24VDC 0VDC 24VDC 0VDC 24VDC 0VDC 24VDC 0VDC
PTAB02
0VDC 24VDC 0VDC 24VDC 0VDC 24VDC 0VDC 24VDC
The PTAB01 or PTAB02 must be set at controller switch-on otherwise the turret cannot start and
ALARM 77 appears.
SELECTION OF LOW/HIGH INERTIA
The turret can be easily configured to drive two ranges of inertia just setting a signal in the control unit.
No mechanical operations or part replacement are required
Standard inertia (LEVEL 1) High inertia (LEVEL 2)
PTAB03
connected to 24VDC not connected
SELECTION OF STANDARD/MAINTENANCE SPEED
This input can be used to slow-down immediately the turret in front of dangerous operations (door opening,
maintenance operations). The speed is about the 20% of the nominal speed.
Connect the SPDSEL input to the 24VDC supply if not used. If the maintenance speed is set during the
movement, it is kept until the end of positioning.
Standard speed Maintenance speed
SPDSEL
connected to 24VDC not connected
