Duplomatic DDC4-10-400/20 User Manual

DUPLOMATIC E.M.DDC4-400V/RK RELEASE 1.9 07-09
EM DDC4-400-RK-0709gb.doc 4
1. GENERAL INFORMATION
The Duplomatic control unit is a compact system that controls all functions regarding positioning and driving of
the SM* turrets Duplomatic. The interfacing to the lathe is powerful and simplified for an easy installation.
Serial line RS232 is set for diagnostic and remote control by PC.
CODE OF THE CONTROL UNIT
DUPLOMATIC
AUTOMAZIONE
MADE IN ITALY
Model: DDC4-10-400/20
Code: 0496320A03
S/N *********
DSP FW 2.4
I/O FW 5
TABLE SET 0489100
TABLE
SELECT
3-SM16
INERTI
A
LEV.1 LEV.2
J (kgm
2
) 1,2 2,2
PTAB03 24V 0V
TOOLS 8 12
PTAB01 24V 0V
PTAB02 0V 24V
MAIN DIFFERENCES WITH DDC2 CONTROL RACK
1) New DDC4 controller inside: more robust – full digital DSP driven.
2) No 230V AC auxiliary supply: only 24V DC supply required. Connector X5 is kept for compatibility but
no more used. The CM1 supply therefore requires a little more current, so Fuse F7 now is set to 1 A T.
3) New Diagnosis software required (DDC4SW*.EXE).
4) No EPROM to change parameters: number of tools and turret model can be changed by the diagnosis
software.

Duplomatic DDC4-10-400/20 Specifications

General

Brand	Duplomatic
Model	DDC4-10-400/20
Category	Control Unit
Language	English
