Dura Heat DFA80T User Manual

14
Figure 21. Replacing Fuse
10. REPLACING FUSE
NOTICE : This heater is fuse protected.
If your
heater fails to ignite, DO NOT RETURN YOUR HEATER TO THE
STORE.
Please follow the simple instructions below to inspect and change the fuse.
WARNING : SHOCK HAZARD
To prevent personal injury, unplug the power cord before replacing fuse.
1. Unplug heater.
2. Remove side cover screws using medium phillips screw driver.
3. Disconnect switch wires from power switch.
4. Remove fuse from fuse holder.(See Figure 21.)
5. Replace fuse.
WARNING : FIRE HAZARD
6. Replace switch wires to power switch.
7. Replace side cover.
PROCEDURE FOR REPLACING FUSE
Fuse Holder
Fuse Holder
DFA80T/135C/180CV/220CV Models
DFA50 Model
Fuse
Fuse
Switch Wire
Power Switch
Side Cover
Screw
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
http://worldmkting.com/kerosene-forced-air-heater-tech-support
