4
Figure 4. DFA50 / 80T MODELS
Figure 5. DFA135C / 180CV / 220CV MODELS
3. UNPACKING AND ASSEMBLY
1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5)
NOTE : Save the shipping carton and packing materials for future storage.
DFA50/80T DFA135C DFA180CV DFA220CV
Wheel Support Frame No Yes Yes Yes
Wheel No Yes Yes Yes
Threaded Axle No Yes Yes Yes
Front Handle No Yes Yes Yes
Rear Handle No Yes Yes Yes
Handle Yes No No No
Cord Wrap No No Yes Yes
Wheels
(10” Flat Free)
Cord Wraps
Screws
Nuts Cap Nuts S
Hardware Kit : HW-KFA1016
Bushings Cap Nuts L
Flange Screws
Front Handle
Threaded Axle
Wheel Support Frame
Rear Handle
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Hardware kit : HW-KFA1016 No Yes Yes Yes
Handle
To Next Page
