14 EATON Series 1 Heavy Duty Hydrostatic Fixed Displacement Motors Parts and Repair E-MOPI-TS002-E September 2004
Speed Sensor Kits
Magnetic Speed Sensor Kit
Kit No. 9900002-000
QTY PART NO. DESCRIPTION
1 106524-000 Speed Pickup
1 105129-000 Washer
1 105132-062 Threaad Seal
1 04-07-707 Installation Instructions
Hall Effect Speed Sensor
Assembly P/N 109823-000
(Ref. Installation Instructions 4-416)
Shaft Bearing
MODEL PART NO. DESCRIPTION
33-46 990014-000 End Cover Bearing Kit
54-64 990016-000 End Cover Bearing Kit
33-46 990089-000 Mounting Flange Bearing Kit
54-64 990387-000 Mounting Flange Bearing Kit
End Cover Shim Kits
MODEL PART NO. DESCRIPTION
33-46 990017-000 End Cover Shim Kit
54-64 990019-000 End Cover Shim Kit
Overhaul Gasket Kits
MODEL PART NO. DESCRIPTION
33-46 990092-001 Overhaul Gasket Kit
54-64 990094-001 Overhaul Gasket Kit
Table 7.0 Service Kits
Shaft Seal Kits
990709-000 Shaft Seal Kit (Lip Design)
For Models 3333/3933/4633/5433/6433
PART NO. QTY. DESCRIPTION
108395-000 1 Drive Shaft Seal
101680-250 1 Retaining Ring
107836-000 1 Spacer
990231-000 Shaft Seal Kit (Mechanical Face Seal)
For Models 3331/3931/4631/5431/6431
PART NO. QTY. DESCRIPTION
102591-000 1 Stationary Seal S/A
96108-281 1 Retaining Ring
102419-000 1 Rotating Seal
104166-131 1 O-Ring
Quadrature Speed Sensor
Kit No.9900121-001
QTY PART NO. DESCRIPTION
1 114264-001 Quadrature speed Sensor(two speed signals in
quadrature with 1 pulse per target tooth)
1 E-MOPI-TI-002-E Installation Instructions
Quadrature Speed Sensor
Kit No.9900121-002
QTY PART NO. DESCRIPTION
1 114264-002 Quadrature speed Sensor (2-pulse per target
tooth signal and 1 directional signal)
1 E-MOPI-TI-002-E Installation Instructions
Parts
Kits
(Item 4)
To Next Page
