Fault codes and troubleshooting
Eaton 1250W / 1500W / 1800W Inverter Operation and Installation Guide IM SP180164 / Rev D www.eaton.com
Fault codes and troubleshooting
Inverter Section
Table 3. DC Input Warning and Shutdown
• Unit start up voltage (Lo setting): > 10.5 +/- 0.3 VDC and < 16.0 +/- 0.3 VDC
• Unit start up voltage (Mid setting): > 11.8 +/- 0.3 VDC and < 16.0+/- 0.3 VDC
• Unit start up voltage (Hi Setting): > 12.2 +/- 0.1 VDC and < 16.0 +/- 0.3 VDC
ote:N
1. Unit will shut down instantly and restart automatically if voltage returns to less than 15.5V within 30 seconds
2. If DC voltage is not less than 15.5V within 30 seconds, unit will require manual reset by power button
3. Unit will shut off instantly if DC voltage drops below 10V regardless of settings
4. Unit will shut off if DC voltage is below shutdown for 10 seconds
5. Unit will shut off if DC voltage is below shutdown for 90 seconds
6. Unit will shut off if DC voltage is below shutdown for 2 minutes
Table 4. AC output overload protection and warning shutdown
Model Condition Display Audible alarmPower (W)
12-110-1800-xx
Warning (+/- 100W) 2000 E06 Beep @ 0.33Hz
Shutdown (+/- 100W) 2100 E03 Beep @ 1Hz
12-110-1500-xx
Warning (+/- 100W) 1700 E06 Beep @ 0.33Hz
Shutdown (+/- 100W) 1800 E03 Beep @ 1Hz
12-110-1250-xx
Warning (+/- 100W) 1450 E06 Beep @ 0.33Hz
Shutdown (+/- 100W) 1550 E03 Beep @ 1Hz
AC output short circuit protection
A short circuit may be applied to the AC output continuously during inverter mode without damage to any components. Unit
will shut down within 10 seconds, and display will indicate ‘E03’ with the buzzer beeping @ 1 Hz.
ote:N Manual reset is required to restart Inverter after AC Overload or Short Circuit shutdown. System will automatically
reset AC Overload or Short Circuit shutdown error when utility is available. The supplemental protector or the branch
protection specified in the Installation Guide should be open under bypass short circuit output condition.



Condition
Disconnect
setting
Setting
(+/-0.3V)
Recovery
(+/-0.3V)
Display
AudibleAlarm
Comment
Over voltage instant shutdown Lo, mid or hi 16.0 15.5 E02 Beep @ 1Hz Notes 1, 2
Under voltage instant shutdown
Lo, mid or hi
10.0
--
--
--
Note 3
Under voltage shutdown
Lo
10.5
12.0
E01
Beep @ 1Hz
Note 4
Under voltage warning Lo 11.0 11.3 E05 Beep @ 0.33Hz --
Under voltage shutdown Mid 11.8 12.3 E01 Beep @ 1Hz Note 5
Under voltage warning Mid 11.8 12.1 E05 Beep @ 0.33Hz --
Under voltage shutdown
Hi
12.2
12.7
E01
Beep @ 1Hz
Note 6
Under voltage warning
Hi
12.2
12.5
E05
Beep @ 0.33Hz
--

