Specifications
Eaton 1250W / 1500W / 1800W Inverter Operation and Installation Guide IM SP180164 / Rev D www.eaton.com
Table 15. Mechanical Specifications
Vibration
Per SAE J1455 Rev JAN2011,
Sec 4.10.4.2, Fig. 6-8, 22 hr/axis
Must operate per specification
during and after the test.
Table 16. Environmental Specifications
Temperature cycling
Per SAE J1455, Rev. JUN2006,
Sec. 4.1, Test 4.1.3.1, Fig. 2B
Must operate per specification
during and after the test.
Thermal shock
Per SAE J1455, Rev. JUN2006,
Sec. 4.1, Test 4.1.3.2 Fig. 2C
Must operate per specification
after the test.
Humidity
Per SAE J1455, Rev. JUN2006,
Sec. 4.2, Fig. 4B
Must operate per specification
during and after the test.
Altitude - operating
Per SAE J1455, Rev. JUN2006,
Sec. 4.9, Table 2
Must operate per specification
during and after the test.
Altitude – non-operating
Per SAE J1455, Rev. JUN2006,
Sec. 4.9, Table 2
Must operate per specification
after the test.
Table 17. Electromagnetic Specifications
Conducted immunity
Per SAE J1113/3, Severity Level
L6 (0.5W)
Manual restart required for
pulses 1, 2b, and 4
Radiated RF immunity - bulk current
injection
Per SAE J1113/4, Class C,
Region 2, 80mA
Immunity to radiated RF
Per SAE J1113/25 to 500 MHz
Per SAE J1113/27 500 MHz to
2 GHz
Load dump
Per SAE J1455, Rev. JUN2006,
Sec. 4.11.2.2.1
Jump start test
Per SAE J1455, Rev. JUN2006,
Sec. 4.11.1
24 Vdc Applied to DC Terminals
The inverter system should
restart without a fault.
Reverse polarity test
Per SAE J1455 Sec. 4.11.1
–24 Vdc Applied to DC Terminals
The inverter shall present no
safety hazard. Internal fuses
will open in the inverter system,
requiring factory service for
replacement.
Table 18. Regulatory Requirements
UL458
Comply with the requirements of
the standard.
ETLus Mark
CSA C22.2, No. 107.1
Comply with the requirements of
the standard.
cETL Mark
47 CFR FCC Part 15, Subpart B,
Class B 2016
Comply with the requirements of
the standard.
FCC Mark
