INSTALLATION
Eaton 5125 Tower UPS (1000–2200 VA) User's Guide S 05147304 Rev C www.eaton.com/powerquality
24
UPS Rear Panels
This section shows the rear panels of the Eaton 5125 models.
X-Slot
Communication
Bay
6‐ft Power Cord
with 5‐15 Plug
Battery
Connector
Network Transient
Protector
Six 5-15R
Receptacles
Communication
Port
Figure 7. PW5125 1000 and PW5125 1500 Rear Panel
6‐ft Power Cord
with 5‐20 Plug
Battery
Connector
Network Transient
Protector
Six 5-15R
Receptacles
Two 5-20R
Receptacles
X-Slot
Communication
Bay
Communication Port
Figure 8. PW5125 2200 Rear Panel
