Eaton 5E User Manual

DSD-5E2206
11
•
•
•
•
Normal mode
When the symbol is illuminated in green, the UPS is providing protected AC power output. The UPS charges the
batteries and provides power protection to your equipment.
Battery mode
When the UPS is operating during a power outage, the alarm beeps once every five seconds and the indicator
illuminates blinking.
The necessary energy is provided by the battery.
When the utility power returns, the UPS transfers to Normal mode operation while the battery recharges.
If battery capacity becomes low while in Battery mode, the audible alarm beeps faster.
This warning is approximate, and the actual time to shutdown may vary significantly; gracefully shutdown all applications on
connected equipment due to imminent UPS shutdown.
When utility power is restored after the UPS shuts down, the UPS automatically restarts.
Low-battery warning
The indicator blinking quickly.
The audio alarm beeps every 1.5 seconds.
The remaining battery power is low. Shut down all applications on the connected equipment becauseautomatic UPS
shutdown is imminent.
End of battery backup time
All the LEDs go OFF.
The audible alarm stops.
5.5 Return of AC input power
Following an outage, the UPS restarts automatically when AC input power returns(unless the UPS is not shut-down by
backup end)and the load is supplied again.
6 UPS maintenance
6.1 Equipment care
For the best preventive maintenance, keep the area around the equipment clean and dust free. If the atmosphere is very
dusty, clean the outside of the system with a vacuum cleaner.
For full battery life, keep the equipment at an ambient temperature of 25 °C (77 °F).
The batteries are rated for a 3-5 year service life. The length of service life varies, depending on the frequency of usage
and ambient temperature (life divided by 2 each 10 °C above 25 °C).
If the UPS requires any type of transportation, verify that the UPS is turned off.
Batteries used beyond expected service life will often have severely reduced runtimes. Replace batteries at least every 4
years to keep units running at peak performance.
Batteries runtime will be reduced at low temperature (below 10 °C).

Eaton 5E Specifications

General

Noise level	45 dB
Output power	1200 W
UPS topology	Line-Interactive
Input frequency	50/60 Hz
Maximum current	10 A
Output power capacity	2 kVA
Surge protection features	Fax, Modem, Telephone
Input operation voltage (max)	280 V
Input operation voltage (min)	170 V
Output operation voltage (max)	- V
Output operation voltage (min)	230 V
Power plug	C14 coupler
AC outlet types	C13 coupler
AC outlets quantity	6 AC outlet(s)
USB 2.0 ports quantity	1
Battery voltage	12 V
Battery capacity	9 Ah
Battery recharge time	6 h
Number of batteries supported	2
Typical backup time at full load	50 min
Typical backup time at half load	26 min
Form factor	Tower
Certification	CE, CB
Product color	Black
LED indicators	Yes
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	330 mm
Width	133 mm
Height	180 mm
Weight	10460 g
