１８
6.2 Operating environment:
Temperature Humidity Altitude Storage temperature
0C-40C <95% <1000m 0C-40
Note: if the UPS is installed or used in the location where the altitude is over 1000m, the output power must
be derated, please refer to the following:
Altitude (M) 1000 1500 2000 2500 3000 3500 4000 4500 5000
Derating Power 100% 95% 91% 86% 82% 78% 74% 70% 67%
6.3 Dimensions and weights:
Model No. Dimensions W x D x H (mm) Net Weight (kg)
1000H 145X400X220 14
1000HXL 145X400X220 7
2000H 192X460X340 34.5
2000HXL 192X460X340 15
3000H 192X460X340 35.5
3000HXL 192X460X340 16
6000H 260 X570 X717 90
6000HXL 260 X570 X717 35
10000H 260 X570 X717 93
10000HXL 260 X570 X717 38
6.4 Battery and typical energy storage time (Typical values at 25°C in
minutes):
Model No. 1000H 2000H 3000H
Number and type
3×12V 7.2Ah 8×12V 7.2Ah 8×12V 7.2Ah
100 % Load 5 9 5
50 % Load 14 21 15
To Next Page
