Eaton 9355 UPS (10/15 kVA) User’s Guide 164201594—Rev H0 105
Table 18. Model Specifications
10 kVA Model
Output Voltage (Line Line)
208 208 208 220
Output Voltage (Line Neutral)
120 120 120 127
Input Voltage
208
480 (with input
isolation
transformer)
600V (with input
isolation
transformer)
220
Input Current
32.2A 16A 13.3A 30.5A
Output Current
27.8A 27.8A 27.8A 26.2A
Output kVA
10 10 10 10
Output kW
9 9 9 9
Efficiency (Minimum)
89% 83% 83% 89%
Heat Rejection [BTU/hr (kg-cal/hr)]
3798 (956) 6294 (1585) 6294 (1585) 3798 (956)
15 kVA Model
Output Voltage (Line Line)
208 208 208 220
Output Voltage (Line Neutral)
120 120 120 127
Input Voltage
208
480 (with input
isolation
transformer)
600 (with input
isolation
transformer)
220
Input Current
48A 24A 20A 45.7A
Output Current
41.6A 41.6A 41.6A 39.4A
Output kVA
15 15 15 15
Output kW
13.5 13.5 13.5 13.5
Efficiency (Minimum)
90% 85% 85% 90%
Heat Rejection [BTU/hr (kg-cal/hr)]
5122 (1290) 8134 (2048) 8134 (2048) 5122 (1290)
Table 19. Battery Specifications
Battery Type
9 Ah sealed, valve-regulated lead acid (VRLA), maintenance-free, minimum 3-year float service
life at 25°C (77°F), voltage 192 Vdc (96 cells per string)
Number of Strings
Maximum of 22 strings per full configuration, including UPS batteries (4 EBM-64 cabinets or
3 EBM-96 cabinets, plus UPS batteries)UPS-32: 2 strings; UPS-64: 4 strings
EBM-64: 4 strings; EBM-96: 6 strings
Battery Replacement
Must be replaced by a qualified service technician
Charger
Service configurable 0.5 34A per string, with overall maximum of 34A (limited by input current).
Default: 3.4A per string
Charging
Internal battery: approximately 3 hours to 80% usable capacity at nominal line voltage after full
load discharge
Product Specifications

Eaton 9355 Specifications

General

Efficiency	91 %
Noise level	58 dB
Output power	27000 W
Input frequency	50/60 Hz
Audible alarm(s)	Yes
Input power factor	0.99
Output power factor	0.9
Output power capacity	30 kVA
Input operation voltage (min)	220 V
Input current Total Harmonic Distortion (THD)	5 %
RS-232 ports	1
AC outlet types	-
AC outlets quantity	- AC outlet(s)
Safety	IEC 62040-1-1, IEC 60950, EN 62040-1-1, UL 1778, NOM-0190SCP8-1993
Form factor	Tower
Display type	LCD
Certification	EN 50091-2 Class A\\r UL, cUL, NOM-NYCE
Product color	Black
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	- min
Operating altitude	0 - 3000 m
Storage temperature (T-T)	0 - 25 °C
Operating temperature (T-T)	10 - 40 °C

Weight and Dimensions

Depth	866.14 mm
Width	508 mm
Height	1676.4 mm
