Eaton 9395XC User Manual

90 Eaton 9395XC UPS 1200kW/1200kVA, 1350kW/1350kVA or 1500kW/1500kVA 164001079—Rev 01
Figure 49. One PM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration
Minislot
Interface
E1, E2, E3 E6, E7, E8
48V Battery
UVR
UPS
CABINET
AC Output to
Critical Load
E9,
E10,
E11
Static
Switch
AC Input to
UPS Rectier
3 Wire A-B-C
Rotation
AC Input to
Bypass
3 Wire A-B-C
Rotation
Interface Board
Battery Aux
Remote EPO
Building Alarms
Alarm Relays
Fuse
Battery
Converter
Inverter
Fuse
Rectier
Input
Contactor
(K1)
Fuse
PM
Battery
Breaker
BATTERY SYSTEM
E4, E5
(Not supplied with the UPS)
A
B
C
D
Single-Feed Kit
EXTERNAL
BATTERY
CABINET
NOTE AC input to rectier is not used in single feed conguration. Dashed lines indicate optional features/components
NOTE Customer supplied bypass input breaker with 48-60VDC UVR is required unless I/O cabinet with Bypass Contactor is selected.
NOTE Callout letters
A , B , C , and D map to the 480V Input/Output Ratings and External Wiring Requirements Table in Chapter 3.
(optional)
K5
