Eaton 9395XC User Manual

Eaton 9395XC UPS 1200kW/1200kVA, 1350kW/1350kVA or 1500kW/1500kVA 164001079—Rev 01 139
CChhaapptteerr 1100 PPrroodduucctt SSppeecciiffiiccaattiioonnss
1100..11 MMooddeell NNuummbbeerrss
The UPS is housed in two free-standing cabinets with safety shields behind the door and front panels. The UPS
is available in 50 or 60 Hz with various output power ratings.
Model Power Rating Frequency
Eaton 9395XC-1200/1200 1200 kW, 1200 kVA 50/60 Hz
Eaton 9395XC-1350/1350 1350 kW, 1350 kVA 50/60 Hz
Eaton 9395XC-1500/1500
1500 kW, 1500 kVA 50/60 Hz
1100..22 SSppeecciiffiiccaattiioonnss
The following sections detail the input, output, environmental, and battery specifications for the UPS.
1100..22..11 UUPPSS IInnppuutt
Operating Input Voltage 480 Vac
Operating Input Frequency Range 50/60 Hz
Operating Input Current See Table 5
Reduced for Generator Adjustable
Input Current Harmonic Content <3% THD at full load
Power Factor Minimum 0.99 at full load
Line Surges 6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801-4
Battery Voltage 480 Vdc
Battery Charging Capacity Up to 480A with less than 85% load
Up to 80A with 100% load
Battery UVR 48 Vdc
