Eaton 9395XC User Manual

Eaton 9395XC UPS 1200kW/1200kVA, 1350kW/1350kVA or 1500kW/1500kVA 164001079—Rev 01 81
Table 21. Pull-Chain Wiring Terminations with MOBs (Continued)
From
To Function
UPS 1 J19 – PULL CHAIN/REM EPO
RTN
MOB 1 AUX 2 COM Pull Chain Common
UPS 1 J19 – PULL CHAIN
MOB 1 AUX 2 NO Pull Chain
UPS 2 CN5 – BLD ALARM 5 RTN
MOB 2 AUX 1 COM
MOB Open Alarm
UPS 2 CN5 – BLD ALARM 5
MOB 2 AUX 1 NC
UPS 2 J19 – PULL CHAIN/REM EPO
RTN
MOB 2 AUX 2 COM Pull Chain Common
UPS 2 J19 – PULL CHAIN
MOB 2 AUX 2 NO Pull Chain
UPS 3 CN5 – BLD ALARM 5 RTN
MOB 3 AUX 1 COM
MOB Open Alarm
UPS 3 CN5 – BLD ALARM 5
MOB 3 AUX 1 NC
UPS 3 J19 – PULL CHAIN/REM EPO
RTN
MOB 3 AUX 2 COM Pull Chain Common
UPS 3 J19 – PULL CHAIN
MOB 3 AUX 2 NO Pull Chain
UPS 4 CN5 – BLD ALARM 5 RTN
MOB 4 AUX 1 COM
MOB Open Alarm
UPS 4 CN5 – BLD ALARM 5
MOB 4 AUX 1 NC
UPS 4 J19 – PULL CHAIN/REM EPO
RTN
MOB 4 AUX 2 COM Pull Chain Common
UPS 4 J19 – PULL CHAIN
MOB 4 AUX 2 NO Pull Chain
