Eaton 9SX 8000 User Manual

Page 41
8-11kVA EU_EN
ENGLISH
9. Specifications
9.1 Model specications
Table 1. Power Module model list
Model Power Ratings
9SX8KiPM 8000VA / 7200W
9PX8KiPM 8000VA / 7200W
9SX11KiPM,
9PX11KiPM
10000VA / 9000W at 200V, 208V, 250V output
11000VA / 9900W at 220V output
11000VA / 10000W at 230V, 240V output
Table 2. Extended Battery Module model list
Model Configuration Battery voltage For power ratings
9SXEBM240 Rack / Tower 240Vdc 8000-11000VA
9PXEBM240 Rack / Tower 240Vdc 8000-11000VA
Table 3. Weights and dimensions
Model (Power Module) Dimensions D x W x H (mm / inch) Weight (lb / kg)
9SX8KiPM
700 x 440 x 130 (27.6 x 17.3 x 5.1)
42 / 19
9PX8KiPM
700 x 440 x 130 (27.6 x 17.3 x 5.1)
42 / 19
9SX11KiPM
700 x 440 x 130 (27.6 x 17.3 x 5.1)
46 / 21
9PX11KiPM
700 x 440 x 130 (27.6 x 17.3 x 5.1)
46 / 21
Model (EBM) Dimensions D x W x H (mm / inch) Weight (lb / kg)
9SXEBM240
680 x 440 x 130 (26.8 x 17.3 x 5.1)
128 / 58
9PXEBM240
680 x 440 x 130 (26.8 x 17.3 x 5.1)
143 / 65
Table 4. Electrical input
Nominal frequency 50/60Hz auto-sensing
Frequency range 50Hz : 40-60Hz before transfer to battery
60Hz : 50-70Hz before transfer to battery
Bypass voltage range -20% / +15% of nominal value (default)
Noise filtering MOV for normal and common mode noise
Model Default input
(Voltage/Current)
Selectable input
Voltage range
Voltage
at 100% Load
9SX8KiPM 230V / 33.1A 200V, 208V, 220V,
230V, 240V, 250V
176-276V
9PX8KiPM
9SX11KiPM 230V / 45.8A 200V, 208V, 220V,
230V, 240V, 250V
176-276V
9PX11KiPM
Table 5. Electrical input connections
Model Input connection Input cable
9SX8KiPM Hardwired Not provided
9PX8KiPM
9SX11KiPM
9PX11KiPM
