Eaton EX 700 User Manual

Output personalization
Function Factory Setting
Other available
settings
Comments
Output voltage
(1)
120 Volts AC 100 to 127 Volts AC
Frequency
converter
(1)
Disabled Enabled
The connected devices are never trans-
ferred to the bypass.
Output frequency
(1)
Automatic selection 50 or 60 Hz
User selectable only if the frequency-
converter function is enabled.
Transfer to the
bypass AC input
(1)
Bypass AC power
must be within toler-
ances
Bypass AC power
may be outside
tolerances
Overload level
(1)
100% 30 / 50 / 70% Alarm if threshold is overrun.
(1) These parameters may be modified only when the UPS is OFF. Detailed comments are available in the Personal
Solution-Pac software.
ON/OFF personalization
Function Factory Setting
Other available
settings
Comments
Start on battery
power
Enabled Disabled
Automatic restart Enabled Disabled
The UPS restarts automatically when AC
power returns.
Energy savings Disabled Enabled
When function enabled, battery shuts
down when power drops to <5%.
Detection of phase/
neutral inversion
(SWF)
Enabled Disabled
Neutral inversion (SWF) When function
enabled, the UPS remains OFF if the
system detects phase/neutral inversion.
Battery personalization
Function Factory Setting
Other available
settings
Comments
Battery test Weekly test
No test / daily test /
monthly test
Low-battery warning 20% 0 to 100% Adjustable in 1% steps.
Selection of the
backup time
Automatic detection
of number of battery
modules
13 to 200 Ah
Battery protection
against excessive
discharges
Enabled Disabled
Excessive discharges when function
disabled, EATON warranty no longer
applies.
4.4 Personalization using external software
w Insert the Solution-Pac CD-ROM in the drive.
w On the first navigation screen, select “Point to Point solution” and follow the instructions on how to install the
Personal Solution-Pac software.
w Then select “Settings”, “Advanced settings” and “UPS settings”.
Note that the Linux/Unix/MacOS versions of the
Personal Solution-Pac software do not offer this possibility.
86-86700-00EN A02 - Page 22
4. Access to Maintenance and Personalization Data

Eaton EX 700 Specifications

General

Noise level	45 dB
Output power	630 W
Input frequency	40/70 Hz
Output power capacity	0.7 kVA
Input operation voltage (max)	284 V
Input operation voltage (min)	100 V
Output operation voltage (max)	250 V
Output operation voltage (min)	200 V
Power plug	C14 coupler
AC outlet types	C13 coupler
AC outlets quantity	6 AC outlet(s)
USB 2.0 ports quantity	1
Safety	IEC/EN 62 040-1, IEC/EN 62 040-2, IEC/EN 62 040-3 (VFI-SS-113), IEC/EN 60 950-1 (RD)
Form factor	Tower
Product color	Gray
LED indicators	Yes
Typical backup time at full load	- min
Typical backup time at half load	16 min
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	440 mm
Width	153 mm
Height	242 mm
Weight	12500 g
