Eaton Ex-Lite N Installation & Maintenance Information

IF 1767 • 09/15 Copyright
©
2015, Eaton’s Crouse-Hinds Division Page 9
5.3 TORQUE VERIFICATION
5.4 EXPLOSIVE EVENT REQUIRED
MAINTENANCE
In the event of an explosion within the enclosure, the filter assemblies
and pre-filters must be replaced. Personnel injury or equipment damage
may result from failure to replace the filters with new filters after an
explosion occurs within the enclosure. Inspect all other components
and verify that they are in proper operating condition. Consult Eaton’s
Crouse-Hinds Division for replacement parts as needed.
6. TECHNICAL DATA
6.1 TECHNICAL DATA CHART
Data shown is for standard catalog, 460VAC drives in CT/IH (Constant
Torque with High Overload). Refer to drive manufacturers manual for all
other voltage and performance specifications.
WIRING
DRIVE LINE/LOAD TERMS. DRIVE GROUND I/O TERMINALS DISCONNECT TERMS.
BASIC CATALOG NO. WIRE SIZE TORQUE WIRE SIZE TORQUE WIRE SIZE TORQUE WIRE SIZE TORQUE
ACE-DG1-1 … ACE-DG1-5 26-10 AWG 5.3 IN-LBS 18-10 AWG 10 IN-LBS
24-12
AWG
4.5
IN-LBS
14-6 AWG 31 IN-LBS
ACE-DG1-7 … ACE-DG1-15 20-6 AWG 15.6 IN-LBS 12-6 AWG 10 IN-LBS 14-6 AWG 31 IN-LBS
ACE-DG1-20 … ACE-DG1-25 6-2 AWG 40 IN-LBS 14-4 AWG 10 IN-LBS 14-6 AWG 31 IN-LBS
ACE-DG1-30 6-2 AWG 40 IN-LBS 14-4 AWG 10 IN-LBS 12-1 AWG 35.4 IN-LBS
ACE-DG1-40 6-1/0 AWG 95 IN-LBS 10-1/0 AWG 14 IN-LBS 12-1 AWG 35.4 IN-LBS
ACE-DG1-50 … ACE-DG1-60 6-1/0 AWG 95 IN-LBS 10-1/0 AWG 14 IN-LBS 6-300 KCM 200 IN-LBS
ACE-DG1-75 … ACE-DG1-100 1/0-350 KCM 354 IN-LBS 8-250 KCM 35 IN-LBS 6-300 KCM 200 IN-LBS
HARDWARE GROUND LUGS
COVER BOLTS MANIFOLT BKT STUDS HOSE CLAMPS WIRE SIZE TORQUE
ACE-DG1-1 … ACE-DG1-5 3/4" HEX
40-45
FT-LBS
N/A N/A N/A N/A
14-2/0 AWG
120
IN-LBS
ACE-DG1-7 … ACE-DG1-30 3/4” HEX
9/16” HEX 20 IN-LBS
5/16” HEX
/SLOTTED
20 IN-LBS
ACE-DG1-40 … ACE-DG1-100 7/8” HEX
Horsepower Rating
Base part
number
Nominal HP
(KW)
Max. disconnect
rating (Amps)
Disconnect
fuse rating
Enclosure
size
460V input
ratings (Amps)
Max. output
rating (Amps)
Power loss
(Watts)
Temperature
rating
ACE-DG1-1 1.0 (.75) 30 10 1 2.0 2.2 48 T6
ACE-DG1-2 2.0 (1.5) 30 10 1 3.2 4.3 71 T6
ACE-DG1-3 3.0 (2.2) 30 10 1 4.5 5.6 82 T6
ACE-DG1-5 5.0 (3.0) 30 15 1 7.1 7.6 99 T6
ACE-DG1-7 7.5 (5.5) 30 20 2 10.2 12.0 483 T4A
ACE-DG1-10 10.0 (7.5) 30 30 2 13.0 16.0 539 T4A
ACE-DG1-15 15.0 (11.0) 60 35 2 19.5 23.0 598 T4A
ACE-DG1-20 20.0 (15.0) 60 50 2 25.1 31.0 719 T4A
ACE-DG1-25 25.0 (18.5) 60 60 2 31.6 38.0 764 T4A
ACE-DG1-30 30.0 (22.0) 100 80 2 37.2 46.0 821 T4A
ACE-DG1-40 40.0 (30.0) 100 100 3 48.3 61.0 909 T4A
ACE-DG1-50 50.0 (37.0) 200 110 3 60.4 72.0 1076 T4A
ACE-DG1-60 60.0 (45.0) 200 125 3 71.6 87.0 1222 T4A
ACE-DG1-75 75.0 (55.0) 200 175 3 89.2 105.0 1271 T4A
ACE-DG1-100 100.0 (75.0) 200 175 3 115.3 140.0 1482 T4A
WARNING: BURN HAZARD
To avoid personnel injury, allow sufficient time for the enclosure to
cool prior to servicing.
