User manual SEFELEC 5x Series 61 v1.06
ADJUSTING THE MEASUREMENT TIME
To change the measurement time press the active area of the "Time" line to obtain:
The Permanent mode: a rise time applies to the test and then the output voltage is equal to the
set point. The test is stopped if the user requests to stop the test by pressing the red button on
the front panel.
NOTE
Pressing the
Start push button: For safety reasons, it is necessary to press
the button for a time > 1 second for the device to switch into
measurement
mode. If the button is pressed for too short a time a message will be displayed
momentarily on the LCD screen.
The authorization to press the Start button or
Stop button is confirmed by the lighting of the push buttons in red or green.
STOP
START
