35
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Onboard SATA Mode Enabled
SATA Configuration IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8&IRQ4
USB Functions Enabled
Legacy USB Support Enabled
Help Item
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Options
Disabled
Enabled
OnBoard IDE Controller (Enabled)
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: Disabled, Compatible,
Enhanced.
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Press <Esc> to return to the main menu setting page.
Use this item to enable or disable the onboard IDE interface.
OnBoard SATA Mode (Enabled)
Use this item to enable or disable the onboard SATA mode.
USB Functions (Enabled)
Use this item to enable or disable the USB function.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB device at startup. If detected, the
USB controller legacy mode is enabled. If no USB device is detected, the legacy USB
support is disabled.
