ECS A785GM-M7 User Manual

32
Using BIOS
Advanced Chipset Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Chipset Setup
DRAM Frequency Auto
DRAM Timing Mode Auto
Internal Graphics Mode UMA
GFX Clock Override Disabled
Share Memory Size Auto
Init Display First P
CI
Memory Hole Remapping Enabled
HDMI Audio Enabled
DCT Unganged Mode Always
Help Item
Auto
Limit
Manual
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Opitimized Defaults
F1: General Help

< >
Options
GFX Clock Override (Disabled)
Use this item to enable or disable GFX Clock Override.
Share Memory Size (Auto)
This item lets you allocate a portion of the main memory for the onboard VGA
display application.
Init Display First (PCI)
Use this item to select which graphics controller to use as the primary boot devices.
HDMI Audio (Enabled)
This item is used to enable or disable the NB HDMI audio support.
DCT Unganged Mode (Always)
This item is used to select the DCT mode (DRAM Controller mode).
Memory Hole Remapping (Enabled)
This item is used to select the DCT mode (DRAM Controller mode).
Press <Esc> to return to the main menu setting page.
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
DRAM Timing Mode (Auto)
This item enables you to specify the DRAM timing mode to be configured automati-
cally or manually.
Internal Graphics Mode (UMA)
Use this item to choose the onboard VGA mode. You can select [Disabled] to disable
the onboard VGA, [UMA] to use the system memory.
Warning: If Internal Graphics Mode is Disabled, please do a
Load Default Settings to enable it.
