Using BIOS
Frequency/Voltage Control
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have installed
in your system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Frequency/Voltage Control
Help Item
Advanced Clock Calibration Disabled
CPU Frequency Ctrl: Disabled
CPU/HT Reference Clock (MHz) 200
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
CPU Voltage Disabled
NB Voltage Disabled
CPUNB Voltage Disabled
DIMM Voltage Disabled
Advanced Clock Calibration (Disabled)
This item can enable greater performance turning margin for the AMD Phenom
TM
Black Edition CPUs. The optimal gain can be seen in configurations that use high-
end CPU cooling solution in combination with elevated CPU core voltage (CPUVID)
value. The motherboards that support ¡ °Advanced Clock Calibration¡±-feature
should enable power delivery capabilities that exceed the 140W CPU TDP specifica-
tions in order to maximize the performance tuning potential.
CPUNB Voltage (Disabled)
This item allows users to adjust the CPUNB voltage.
Disabled
Auto
All Cores
Per Core
Options
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
< >
AMD Phenom (tm) II x3 740 Processor
Speed: 3000MHz, NB Clk: 2000MHz
Current CPU Frequency 3000MHz
Current CPU Voltage 1.3250v
Current NB Frequency 2000MHz
CPU Frequency Ctrl (Disabled)
This item allows users to enable or disable CPU frequency control.
CPU/HT Reference Clock (MHz) (200)
Use this item to set the CPU/HT Reference Clock through clock gen.
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Spread Spectrum (Enabled)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
CPU Voltage (Disabled)
This item allows users to adjust the CPU voltage
.
NB Voltage (Disabled)
This item allows users to adjust the NB voltage.
