ECS H57H-M User Manual

35
Using BIOS
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: IDE, RAID, AHCI or
Disabled.
Onboard SATA Mode (AHCI)
Use this ite
m to select the SATA mode.
Onboard SATA2 Controller (IDE Mode)
Use this item to select the mode of the Onboard SATA2 Controller.
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
OnBoard LAN1 Function (Enabled)
Use this item to enable or disable the onboard LAN1 function.
OnBoard LAN2 Function (Enabled)
Use this item to enable or disable the onboard LAN2 function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB device at startup. If detected, the
USB controller legacy mode is enabled. If no USB device is detected, the legacy USB
support is disabled.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Integrated Peripherals
Options
Help Item
SATA Configuration IDE
Onboard SATA Mode Enabled
Onboard SATA2 Controller IDE Mode
Onboard AUDIO Function Enabled
Onboard LAN1 Function Enabled
Onboard LAN2 Function Enabled
Onboard LAN Boot ROM Disabled
USB Functions Enabled
Legacy USB Support Enabled
Press <Esc> to return to the main menu setting page.
IDE
RAID
AHCI
Disabled

F10: Save
: Move
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
ESC: Exit

ECS H57H-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	2.5 GT/s
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
BIOS type	AMI
BIOS memory size	64 Mbit
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H57
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7
Parallel processing technology support	Not supported
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111D(L)
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Width	244 mm
