PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
f
CPU Temperature (DTS) 42
System Temperature 30
O
C
CPU Fan Speed 3308 RPM
System Fan Speed 0 RPM
Processor Input Voltage 1.733V
DIMM Voltage 1.504V
+12V 12.096V
+5V 5.064V
+3.3V 3.410V
TCC Activation Temperature (DTS) 75
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
PC Health Status
Advanced
Smart Fan Function
ff
ff
f
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value / unit
CPU Fan Full Speed Offset (DTS) 52
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
F1:General Help
+/- : Change Opt.
Enter : Select
lk
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
ESC:Exit
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Advanced
System Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value / unit
System Fan Full Speed Offset (DTS) 52
Enable System Smart Fan
mn
F4:Save & Exit
 Smart Fan Function
ff
ff
f
Scroll to this item and press <Enter> to view the following screen:
CPU/System Fan Smart Fan Control (Enabled)
These items enable you to define the CPU/system fan by smartly adjusting the CPU/
system fan. When it is set at certain temperature, the CPU/system fan PWM value
will change accordingly.
