The chipset menu items allow you to change the settings for the SoC chip and other
system.
Chipset Menu
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
System Agent Configuration
PCH Configuration
ME Configuration
f
f
Main Advanced Chipset M.I.B.X Boot Security Exit
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
System Agent (SA) Parameters
Scroll to this item and press <Enter> and view the following screen:
System Agent Configuration
Initiate Graphic Adapter (Auto)
This item allows you to select graphics controller to use as the primary boot device.
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics Device) memory.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Chipset
System Agent Configuration
Initiate Graphic Adapter [Auto]
IGD Memory [64M]
DVMT Memory [256M]
IGD Multi-Monitor [Disabled]
CPU SA Audio Device [Enabled]
Select which of IGFX/PEG/PCI
Graphics device should be Primary
Display Or select SG for Switchable
Gfx.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
f
DVMT Memory (256M)
When set to Fixed Mode, the graphics driver will reserve a fixed positon of the sys-
tem memory as graphics memory, according to system and graphics equirements.
IGD Multi-Monitor (Disabled)
This item allows you to enable or disable the IGD Multi-Monitor.
f
