Chapter 3
Q87H3-M5 USER MANUAL
40
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (AHCI Mode)
Use this item to select SATA mode.
SATA Port1~5 (Not Present)
This motherboard supports five SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
Press <Esc> to return to the Advanced Menu page.
SATA Configuration
SATA Mode [AHCI Mode]
SATA Port1
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Determines how SATA controllers
operate.
Advanced
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
f
SATA Port2
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port3
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port4
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port5
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
Spin up Device (Disabled)
On an edge detect from 0 to 1, the PCH starts a COMRESET inization sequence to the
device.
External SATA (Disabled)
Use this item to enable or disable External SATA Support.
