This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B. X(MB Intelligent BIOS X) Menu
CPU OverClocking Configuration
Scroll to this item to view the following screen:
CPU Ratio (20)
This item allows users to control non turbo CPU ratio.
Package Current Lock (Disabled)
This item allows you to enable or disable the package current lock.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
CPU Ratio 20
Package Current Lock [Disabled]
IA Core Current Maximum
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
Runtime Turbo Enable [Disabled]
Boot Performance Mode [Max Non-Turbo Perfo...]
Package TDP Lock Enable [Disabled]
Long Duration Power Limir Override Maximum
Power Limit 1 Time (Second) 8
Power Limit 2 Switch [Enabled]
Short Duration Power Limit Override Maximum
1 Core Ratio Limit 30
2 Core Ratio Limit 29
3 Core Ratio Limit 27
4 Core Ratio Limit 26
Disable OverClocking Lock [Enabled]
M.I.B.X
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Package Current Lock
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
M.I.B X (MB Intelligent BIOS X)
CPU OverClocking Configuration
North Bridge Configuration
Memory Configuration
Over Voltage Configuration
Spread Spectrum [Auto]
Intel (R) Core (TM) i7-4765T CPU @ 2.00GHz
Processor Speed 2000 MHz
Memory Frequency 1333 MHz
Total Memory 2048 MB (DDR3)
f
f
Main Advanced Chipset M.I.B.X Boot Security Exit
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU OverClocking Configuration
