Acclarix AX3 Series Diagnostic Ultrasound System User Manual Getting Started
- 10 -
3 Getting Started
3.1 System Configuration
Standard Configuration:
The system is shipped with the following components:
 1 main unit
 1 AC adapter
 1 power cord
 1 rechargeable lithium battery
 1 USB disk
 1 bottle of coupling gel
 1 basic user manual and 1 advanced user manual
 1 packing list
Options:
The following options are also available:
 Transducers:
C5-2Q, L12-5Q, E8-4Q, P5-1Q, L17-7Q
 Needle Guide Bracket Kit
Model
Angle/Depth
Description
BGK-C5-2
20° , 28°, 40°
For use with the C5-2Q,
Supports: 14G-23G
BGK-L40UB
34°, 43°, 53°, 66°
For use with the L17-7Q,
Supports: 14G-23G
BGK-001
1.0cm, 1.5cm, 2.0cm
For use with the L17-7Q,
Supports: 21G
BGK-002
38° , 46°, 58°
For use with the L12-5Q,
Supports: 14G-23G
BGK-003
1.0cm, 1.5cm, 2.0cm
For use with the L12-5Q,
Supports: 21G
BGK-CR10UA
2°
For use with the E8-4Q,
Supports: 16G, 18G
Table 3-1 Needle Guide Bracket Kits
 2
nd
rechargeable lithium battery
 Footswitch
 Suitcase
