EDAN SD5 User Manual

SD5/SD6 Ultrasonic TableTop Doppler User Manual Introduction
- 6 -
Chapter 2 Introduction
NOTE:
The pictures and interfaces in this manual are for reference only.
2.1 Main Unit
SD5:
SD6:
Figure 2-1 Overview
Figure 2-2 Top View of the Main Unit
1 Probe
2 Probe Cable
3 Main Unit
4 LCD
5 Speakers
6 Probe Socket
8
9
10
7 Probe Holder
8 Handle
9 Probe Sensor Socket
10 Main Unit Control Keys
1
2
3
4
5
6
5
3
4
5
5
7
1

EDAN SD5 Specifications

General

Brand	EDAN
Model	SD5
Category	Medical Equipment
Language	English
