SD5/SD6 Ultrasonic TableTop Doppler User Manual Recording and Playing
- 25 -
Chapter 5 Recording and Playing
The built-in recorder of the Doppler allows recording and playing fetal heart sound of 240
seconds (at most).
To record fetal heart sound:
Press and hold the Record/Play control key for two seconds. The character REC on the
LCD lights up. Recording starts.
Press the Record/Play control key again to stop recording and return to the real-time
examining mode.
To play the fetal heart sound:
Press the Record/Play control key in the real-time examining mode. The character PLA on
the LCD lights up. The Doppler plays the recorded fetal heart sound.
NOTE:
Observe the LCD, pay attention not to mistake the recorded fetal heart sound for the
real-time sound.
