Loading...How to adjust the brightness on my Eizo Monitor if the screen is too bright or dark?
If your Eizo monitor screen is too bright or too dark, use the “Brightness” or “Contrast” settings in the Setting menu to adjust it. If the screen is too bright, you can also try turning on the Auto EcoView feature.
How to fix an Eizo Monitor when there is no picture and the power indicator doesn't light up?
If your Eizo monitor shows no picture and the power indicator is off, try these steps: First, ensure the power cord is properly connected. Then, turn on the main power switch. Next, press the power button on the monitor. If the issue persists, turn off the main power, wait a few minutes, and then turn it back on.
Why is there no audio output from my Eizo FlexScan EV2736W?
If you're experiencing no audio output from your Eizo monitor, consider the following: Check that the stereo mini jack cable is correctly connected. Ensure the volume isn't set to 0. Verify the settings on your PC and audio playback software. If using DisplayPort, check the “Source” setting.
What to do if USB devices connected to my Eizo FlexScan EV2736W Monitor don't work?
If USB devices connected to your Eizo monitor aren't working, try these solutions: Check if the USB cable is correctly connected. Try using a different USB port. Reboot your PC. Also, ensure that your PC and operating system are USB compliant.
What to do if my Eizo FlexScan EV2736W Monitor has no picture and the power indicator is lighting orange?
If your Eizo monitor displays no picture but the power indicator is orange, try these steps: Switch the input signal using the appropriate button. Move the mouse or press any key on the keyboard. Check whether the PC is turned on. Come near to the monitor. If the screen is still not displayed, move the mouse or press any key on the keyboard.
How to resolve 'Input Signal Out of Range' on my Eizo FlexScan EV2736W Monitor?
If your Eizo monitor displays a message indicating that the input signal is out of the specified frequency range, check whether your PC is configured to meet the monitor's resolution and vertical scan frequency requirements. You might also need to reboot your PC or select an appropriate setting using your graphics board’s utility.
Why are the characters blurred on my Eizo FlexScan EV2736W?
If the characters on your Eizo monitor appear blurred, check whether your PC is configured to meet the monitor's resolution and vertical scan frequency requirements. If you're using a resolution other than the recommended one, use the “Smoothing” and “Screen Size” settings in the Setting menu to adjust the display.
What to do if my Eizo Monitor has no picture, but the power indicator is blue?
If your Eizo monitor shows no picture, but the power indicator is lighting blue, increase the “Brightness”, “Contrast”, or “Gain” in the Setting menu.
Why does EcoView Sense on my Eizo FlexScan EV2736W Monitor not work correctly?
If the EcoView Sense feature on your Eizo monitor isn't working correctly (images remain displayed when you move away or don't reappear when you come near), check the monitor's setting environment. Ensure there's no dirt on the sensor and clean it with a soft cloth if necessary. Also, make sure you are directly in front of the monitor. If the screen remains off, try turning the monitor off and on using its power button.
How to prevent afterimages on my Eizo Monitor?
To prevent afterimages on your Eizo monitor, avoid displaying the same image for a long time. Use the screen saver or power save function to prevent static images from being displayed for extended periods.
General| 3D | No |
|---|---|
| Pixel pitch | 0.233 x 0.233 mm |
| Aspect ratio | 16:9 |
| Response time | 6 ms |
| Display diagonal | 27 \ |
| Display technology | LED |
| Viewable size, vertical | 335.6 mm |
| Contrast ratio (dynamic) | - |
| Contrast ratio (typical) | 1000:1 |
| Display number of colors | 16.78 million colors |
| Viewable size, horizontal | 596.7 mm |
| Display brightness (typical) | 300 cd/m² |
| Supported graphics resolutions | 2560 x 1440 |
| HDCP | Yes |
| USB hub version | 2.0 |
| DVI-D ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| VGA (D-Sub) ports quantity | 0 |
| USB Type-A downstream ports quantity | 2 |
| RMS rated power | 2 W |
| Number of OSD languages | 9 |
| Panel mounting interface | 100 x 100 mm |
| Power consumption (max) | 67 W |
| Power consumption (standby) | - W |
| Power consumption (typical) | 24 W |
| Power consumption (PowerSave) | 0.5 W |
| Certification | TCO Displays 6.0, ECO Sense Gold, ISO9241-307, TUV/GS, c-Tick, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, GOST-R |
| Product color | Gray |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
Weight and Dimensions| Depth (without stand) | 65 mm |
|---|---|
| Width (without stand) | 640 mm |
| Height (without stand) | 379 mm |
| Weight (without stand) | 7300 g |
Overview of the monitor's key capabilities, including screen size, panel type, and connectivity.
Details on included software like ScreenManager Pro for screen adjustment and utility disk contents.
Lists supported display resolutions for DVI-D and DisplayPort inputs.
Step-by-step guide to adjust screen resolution on Windows and Mac OS.
Guides on adjusting brightness, contrast, gamma, saturation, hue, overdrive, and gain.
How to choose preset display modes like sRGB, Paper, or Movie for optimal viewing.
Options for adjusting image display size and improving text/line clarity.
Configuration options for volume, sound source, DDC/CI, language, and logo display.
How to prevent accidental changes to monitor settings by locking buttons.
How to reposition the on-screen display (OSD) menu.
Returns all monitor settings, including color and EcoView Sense, to factory defaults.
How to enable or disable monitor power saving and manage power indicator status.
Utilizes ambient light sensor to automatically adjust screen brightness.
Configures power saving based on user presence using the EcoView Sense function.
Automatically turns off the monitor after a set period in power saving mode.
Solutions for common problems like no display or incorrect power indicator status.
Addresses issues like screen brightness, blurred text, afterimages, and display defects.
Covers issues such as inaccessible menus, no audio, and USB device malfunctions.
Instructions for mounting the monitor using its stand or an optional VESA arm.
How to use the included cable holder to organize monitor cables.
How to configure the monitor to automatically or manually select input signals.
Connecting peripheral USB devices via the monitor's built-in USB hub.
Detailed technical specifications and performance characteristics of the monitor.
Terms and conditions of the product's warranty coverage and limitations.
Guidelines for environmentally responsible disposal and recycling of the product.
Information regarding compliance with regulations like FCC and China RoHS standards.
