elco THISION L EVO Series User Manual

Page 13 of 33
3. Flue Components
3.1 Available Flue Components
21
9
Available Flue Parts:
1. Wall Terminal
2. 2000mm Concentric Pipe
3. 500/1000mm Concentric Pipe
4. 90° Concentric Bend
5. 45° Concentric Bend
6. Vertical Adaptor
7. Roof Terminal
8. Flat Roof Flashing
9. Pitched Roof Flashing
10. Wall Bracket
11. Concentric Increaser
12. 2000/1000/500mm PPs Pipe
13. 90° PPs Bend
14. 45° PPs Bend
15. Plume Kit
16. PPs Increaser
17. Bird Mesh Stainless Steel Guard
18. Air Filter
19. Concentric to Parallel Adaptor
20. Air Inlet Cover
21. Parallel to Concentric Adaptor
22. PPs Reducer
*Products supplied may differ from image
1
3
2
13
12
14
15
8
16
17
18
7
11
10
6
5
4
19
20
22
