3.4 Thision L Eco Flue Components
Concentric Flue System
Item
Flue Component
100/150
2
1950mm Length
3791303
3
1000mm Length
3791304
3
500mm Length
3791305
4
87°/93° Bend
3791306
5
45° Bend
3791307
1
Wall Terminal
3791308
1 + 4
*Wall Terminal Kit
FLUE-B-EVOWALL
7
Roof Terminal
3791309
8
Flat Roof Slate
3791617
9
Pitched Roof Slate
3791618
10
Flue Bracket
3791616
15
Plume Kit
3791480
*Wall terminal kit includes wall terminal and 87°/93° bend
Single/Two Pipe Flue System
Item
Flue Component
100mm
12
1950mm Length
3791297
12
1000mm Length
3791299
12
500mm Length
3791594
13
87°/93° Bend
3791300
14
45° Bend
3791301
17
Mesh Terminal
3791607
10
Flue Bracket
3791302
15
Plume Kit
3791480
18
Air Filter
3905046
20
Air Inlet Cover
452002280
